WebRTC Load Testing: Tools, Metrics and Method

WebRTC load testing is about throwing a bunch of fake participants at your media server and keeping an eye on two things at the same time: what the server is doing (CPU, bandwidth) and what each participant would actually feel (packet loss, jitter, round-trip time, frozen video). A server's CPU graph on its own can be misleading. You might see 60% CPU while everyone hears garbled audio, and the opposite can happen too.

This guide isn't tied to any single server. It walks through the method, the Chrome flags that let you fake a camera, a rundown of the tools worth knowing, a Puppeteer script you can tweak for any browser-based app, and the common mistakes that quietly mess up your numbers. If you're running Jitsi and want the step-by-step for that platform, our Jitsi load testing guide with Malleus goes deeper. For background on what you're actually testing, start with WebRTC architecture explained.

What to Measure

Decide your pass/fail numbers before you run anything. "200 participants for 30 minutes with packet loss under your limit and no frozen video" is a test. "See how it goes" is a demo. The thresholds depend on your product (a webinar tolerates things a doctor's video call does not), so pick yours, write them down, then test.

On the client side, every browser exposes what you need through RTCPeerConnection.getStats(). These are the fields worth collecting:

• Packet loss: packetsLost against packets received, on inbound streams.
• Jitter: how uneven packet arrival is. High jitter is what turns into choppy audio.
• Round-trip time: currentRoundTripTime on the active candidate pair.
• Frame rate and freezes, plus resolution. A call can have zero packet loss and still drop to 180p because the server is shedding quality.
• Join time: how long until the first frame renders.

On the server side, watch CPU, network throughput in and out, and memory. An SFU forwards packets instead of decoding them, so the usual bottleneck is bandwidth and packet-forwarding CPU, not video processing. That's also why the load generators, which do decode, end up costing more than the server they're testing.

Fake Cameras With Chrome Flags

Real participants have cameras. Test participants don't, and a headless browser on a server will ask for a camera it doesn't have. Chrome has a set of flags to fix that, documented on webrtc.org's testing page:

• --use-fake-ui-for-media-stream accepts the camera and microphone permission prompt automatically.
• --use-fake-device-for-media-stream replaces the camera and microphone with a synthetic test pattern and beep.
• --use-file-for-fake-video-capture and --use-file-for-fake-audio-capture play a file instead of the test pattern.

The test pattern is fine for a first check. For numbers you can trust, use real footage, because a flat test pattern encodes at a very different bitrate from a person moving around. Chrome accepts .y4m and .mjpeg files as fake video sources, which ffmpeg can make from any clip:

# 10 seconds of 640x360 video at 15 fps, raw y4m (Chrome loops it)
ffmpeg -i source.mp4 -t 10 -vf scale=640:360 -r 15 -pix_fmt yuv420p test.y4m

# 10 seconds of mono 48 kHz audio
ffmpeg -i source.mp4 -t 10 -ac 1 -ar 48000 test.wav

Keep the clip short and the resolution modest. Raw video is enormous (that 10-second clip is already tens of megabytes), and Chrome loops it for the length of the test. Then start a browser with all four flags and open your app:

google-chrome \
  --headless=new \
  --use-fake-ui-for-media-stream \
  --use-fake-device-for-media-stream \
  --use-file-for-fake-video-capture=/opt/media/test.y4m \
  --use-file-for-fake-audio-capture=/opt/media/test.wav \
  https://your-app.example.com/room/load-test

If that one browser joins a room and shows moving video on the other side, the plumbing works. Everything below is about doing it many times at once.

Pick a Load Testing Tool

There are two designs. Some tools drive real browsers, which tests your actual front end but costs a lot of CPU per participant. Others use a lightweight client built on a WebRTC library, which is far cheaper but tests the server and not your web app. OpenVidu's own documentation puts a real Chrome participant at about 1 vCPU and 1 GB of memory, and its emulated participant at about 0.1 vCPU and 0.2 GB. That figure comes from the vendor, so treat it as a rough guide rather than a hard number. A 200-participant browser test, by that math, needs something like 200 vCPU of load generators.

License details matter if you plan to modify a tool or build it into a product. OpenVidu Load Test is Apache 2.0. webrtcperf is AGPL-3.0, which is fine for running tests in-house and something to read carefully before you embed it anywhere. webrtcperf also pushes its metrics to Prometheus through a Pushgateway, so the results land on the same Grafana boards as your server monitoring.

Not sure which server to test in the first place? Our rundown of the best open-source WebRTC media servers covers the options, and LiveKit vs Jitsi compares the two we see most.

Run a LiveKit Test

LiveKit ships its load tester inside its CLI. It uses the Go SDK to act as publishers and subscribers, and its video publishers send simulcast layers at 720p, 360p and 180p, so the server sees realistic fan-out. Raise the file handle limit first, as LiveKit's docs advise, then start small:

ulimit -n 65535

# Large meeting shape: everyone publishes, everyone subscribes
lk load-test \
  --url wss://livekit.example.com \
  --api-key YOUR_KEY --api-secret YOUR_SECRET \
  --room load-test \
  --video-publishers 10 --subscribers 50 \
  --duration 5m

Flags can change between CLI versions, so check lk load-test --help on yours. For scale, LiveKit publishes its own results from a 16-core c2-standard-16 instance on Google Cloud:

Source: LiveKit's self-hosting benchmark page. Treat these as one vendor's results on one machine shape, not a capacity promise for yours. A user on LiveKit's GitHub reported hitting only 1,500 subscribers on the same hardware, and a maintainer noted the SFU "may not be as efficient as it used to be as we have added more features." Your mileage will vary.

A Browser Test for Any App

When no purpose-built tool exists for your stack, a short script gets you most of the way. The idea has three parts: launch headless Chrome with the fake media flags, wrap RTCPeerConnection before the app loads so you can reach its connections, then poll getStats() on a timer and print what you find.

// load-test.mjs   (Node 20+, npm install puppeteer)
// usage: node load-test.mjs https://your-app.example.com/room/load-test 20 180
import puppeteer from 'puppeteer';

const [, , url, count = '10', seconds = '120'] = process.argv;

// Runs inside every page before the app does, so we can reach its connections later.
const hook = () => {
  const Original = window.RTCPeerConnection;
  window.__pcs = [];
  window.RTCPeerConnection = function (...args) {
    const pc = new Original(...args);
    window.__pcs.push(pc);
    return pc;
  };
  window.RTCPeerConnection.prototype = Original.prototype;
};

async function join(i) {
  const browser = await puppeteer.launch({
    headless: true,
    args: [
      '--no-sandbox', // needed in most containers
      '--use-fake-ui-for-media-stream',
      '--use-fake-device-for-media-stream',
      '--use-file-for-fake-video-capture=/opt/media/test.y4m',
      '--use-file-for-fake-audio-capture=/opt/media/test.wav',
    ],
  });
  const page = await browser.newPage();
  await page.evaluateOnNewDocument(hook);
  // How a name is passed in depends on your app. Adjust this line.
  await page.goto(url + '?name=load-' + i, { waitUntil: 'load' });
  return { browser, page };
}

function sample(page) {
  return page.evaluate(async () => {
    const out = { lost: 0, received: 0, jitter: 0, rtt: 0 };
    for (const pc of window.__pcs || []) {
      const stats = await pc.getStats();
      stats.forEach((r) => {
        if (r.type === 'inbound-rtp') {
          out.lost += r.packetsLost || 0;
          out.received += r.packetsReceived || 0;
          out.jitter = Math.max(out.jitter, r.jitter || 0);
        }
        if (r.type === 'candidate-pair' && r.state === 'succeeded' && r.nominated) {
          out.rtt = Math.max(out.rtt, r.currentRoundTripTime || 0);
        }
      });
    }
    return out;
  });
}

const sleep = (ms) => new Promise((r) => setTimeout(r, ms));
const clients = [];

for (let i = 0; i < Number(count); i++) {
  clients.push(await join(i));
  await sleep(2000); // ramp up, never join everyone at once
}

console.log('seconds,clients,loss_pct,max_jitter_ms,max_rtt_ms');
const started = Date.now();
while (Date.now() - started < Number(seconds) * 1000) {
  const rows = await Promise.all(clients.map((c) => sample(c.page)));
  const lost = rows.reduce((n, r) => n + r.lost, 0);
  const received = rows.reduce((n, r) => n + r.received, 0);
  const jitter = Math.max(...rows.map((r) => r.jitter));
  const rtt = Math.max(...rows.map((r) => r.rtt));
  const loss = (100 * lost) / Math.max(1, lost + received);
  console.log([
    Math.round((Date.now() - started) / 1000),
    clients.length,
    loss.toFixed(2),
    (jitter * 1000).toFixed(0),
    (rtt * 1000).toFixed(0),
  ].join(','));
  await sleep(10000);
}

await Promise.all(clients.map((c) => c.browser.close()));

Be honest about what this is: a starting point. I haven't run it against your app. It assumes the app creates its peer connections in the page itself, and the line that passes a display name is a placeholder you'll have to change. Join flows that need a login, a lobby or a click on a "Join" button need a few lines of Puppeteer to get through, using page.click and page.waitForSelector.

It also doesn't scale forever. Each browser is a full Chrome, so at roughly 1 vCPU per participant you'll outgrow one machine quickly. Run the script on several load generators with a different count on each, and add up the results. If you outgrow even that, webrtcperf already does this job with more polish.

Reading the Results

Plot server CPU, server bandwidth and client packet loss on one timeline against the number of participants. You're looking for the knee: the point where loss or jitter starts climbing while participants keep being added. That participant count, not the point where the server falls over, is your real capacity.

One research result is worth knowing before you trust CPU as your only signal. OpenVidu's team compared Kurento, mediasoup and Pion and reported that for Kurento and Pion, CPU alone tracked quality degradation well, while for mediasoup it did not, and additional WebRTC metrics were needed because quality could stay good even at high CPU. Their research page has the papers. The practical lesson: always collect the client metrics, whatever server you run.

Look at the worst participants, not only the average. An average loss of 0.5% can hide a handful of people at 8%, and those are the ones who file support tickets. When something looks wrong in a single session, debugging WebRTC applications shows how to dig into it with chrome://webrtc-internals.

Test the TURN Path

Most load tests run on a clean network where every call connects directly, so they never touch your TURN server at all. Then launch day arrives, a corporate firewall forces thousands of users through relays, and the load is completely different. Relayed media passes through your TURN server in both directions, which means its bandwidth bill and CPU matter as much as the SFU's.

To test it, force relayed connections in the test clients:

// In the page under test, force every call through TURN
const pc = new RTCPeerConnection({
  iceServers: [{ urls: 'turn:turn.example.com:3478', username: 'user', credential: 'pass' }],
  iceTransportPolicy: 'relay',
});

Run the same test again with everyone relayed and watch the TURN server. If you haven't set one up, our Coturn developer guide deploys one on AWS, and STUN vs TURN vs ICE explains when relays kick in.

Mistakes That Skew the Numbers

• The load generator is the bottleneck. If the machine running the browsers is at full CPU, you're measuring the generator. Watch its CPU too, and add machines before it saturates.
• Everyone joins at once. Real rooms fill gradually. A thundering herd of joins tests your signalling server and ICE handling, which is a separate test. Ramp up, as the script above does.
• Generators in the same rack as the server. No latency, no loss, flattering results. Put them in the same region at least, and ideally somewhere with a real network path in between.
• A test clip that is unlike real video. A static image encodes at a fraction of the bitrate of a person moving. Check the bitrate your fake participants actually send and compare it with a real session.
• Too short. Memory leaks and slow degradation show up after 30 minutes, not 3. Run a ramp test to find the knee, then a long soak test at a participant count just below it.
• Reporting only averages. Use percentiles and the worst few participants.
• Forgetting the cost. A big test moves a lot of bandwidth. Check what your cloud charges for traffic before a 3,000-subscriber run, as our Jitsi self-hosting cost breakdown shows for one platform.

Where I'd Start
