AWS Import Export Guide: VM Import to EC2 and AMI Export

Sometimes the same machine image has to run in two places: on a VMware or VirtualBox host on-premises, and on EC2. AWS VM Import/Export is the service that converts between the two. You upload a disk image to S3, and AWS turns it into an AMI. Or you point it at an AMI, and it writes a VMDK, VHD or raw disk back to S3.

When this guide was first written in 2018, getting it to work took some trial and error: official cloud images downloaded from Canonical refused to import, and only a VM installed from the ISO inside VirtualBox went through. That lesson still holds, and AWS now states it plainly. The commands and limits below are current.

What is AWS Import/Export?

A naming note first, because it trips up a lot of searches. "AWS Import/Export" was originally a physical disk-shipping service: you mailed hard drives to AWS and they loaded the data. That service later became the AWS Snow family. This article is about VM Import/Export, the image conversion service, which is what most people searching for AWS import export today actually want.

When AWS VM Import makes sense

• Moving an existing server image to AWS without rebuilding it, for example an appliance a vendor ships as an OVA.
• Keeping one golden image for on-prem and cloud, built locally and imported.
• Handing an AMI to someone who runs VMware, via export.

If you are migrating many running servers continuously, AWS Application Migration Service is the better tool. VM Import/Export is for one-off image conversions.

Prepare the VM

Most failed imports are decided before you upload anything. Check these against the official requirements:

Inside the guest, make sure networking uses DHCP rather than a static IP, and that you can log in over SSH with a key or password you know. The imported instance boots with whatever network config the image had, and a static address from your office LAN means an unreachable instance.

Then export it. In VirtualBox that is File, Export Appliance, saved as an .ova. Upload it to an S3 bucket in the same region you want the AMI in. If you have not set up the CLI yet, installing AWS CLI v2 covers it, and for multi-gigabyte images uploading large files to S3 explains the multipart settings that keep the upload from crawling:

aws s3 mb s3://my-vm-imports --region eu-central-1
aws s3 cp ubuntu-server.ova s3://my-vm-imports/vms/ubuntu-server.ova

Create the vmimport role

VM Import/Export works on your behalf through a service role that must be named vmimport. Create trust-policy.json:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": { "Service": "vmie.amazonaws.com" },
      "Action": "sts:AssumeRole",
      "Condition": {
        "StringEquals": { "sts:Externalid": "vmimport" }
      }
    }
  ]
}

And role-policy.json, with your import bucket and, if you plan to export, a second bucket for exports:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": ["s3:GetBucketLocation", "s3:GetObject", "s3:ListBucket"],
      "Resource": [
        "arn:aws:s3:::my-vm-imports",
        "arn:aws:s3:::my-vm-imports/*"
      ]
    },
    {
      "Effect": "Allow",
      "Action": ["s3:GetBucketLocation", "s3:GetObject", "s3:ListBucket", "s3:PutObject", "s3:GetBucketAcl"],
      "Resource": [
        "arn:aws:s3:::my-vm-exports",
        "arn:aws:s3:::my-vm-exports/*"
      ]
    },
    {
      "Effect": "Allow",
      "Action": ["ec2:ModifySnapshotAttribute", "ec2:CopySnapshot", "ec2:RegisterImage", "ec2:Describe*"],
      "Resource": "*"
    }
  ]
}

aws iam create-role --role-name vmimport --assume-role-policy-document file://trust-policy.json
aws iam put-role-policy --role-name vmimport --policy-name vmimport --policy-document file://role-policy.json

AWS EC2 import image with the CLI

aws ec2 import-image \
    --description "ubuntu-server from VirtualBox" \
    --license-type BYOL \
    --disk-containers '[{
      "Format": "OVA",
      "UserBucket": {
        "S3Bucket": "my-vm-imports",
        "S3Key": "vms/ubuntu-server.ova"
      }
    }]'

For Linux, BYOL is the right licence type, and it is also what AWS assumes if you leave the flag out. The command returns an ImportTaskId straight away; the conversion runs in the background. Old guides tell you to watch it with describe-conversion-tasks, but that command belongs to the legacy instance-import API. For image imports use:

aws ec2 describe-import-image-tasks --import-task-ids import-ami-0abcd1234example

The status walks through validating, converting, updating, booting and preparing ami, then completed with an ImageId. Launch an instance from that AMI like any other. If you hit a vCPU limit on the first launch in a fresh account, raising the EC2 vCPU quota sorts it out.

AWS export AMI to VMDK, VHD or raw

The 2018 version of this guide said you could only export instances you had previously imported. That was true of the old instance export. Today export-image works on most AMIs you built yourself:

aws ec2 export-image \
    --description "ubuntu-server for VMware" \
    --image-id ami-0abcd1234example \
    --disk-image-format VMDK \
    --s3-export-location S3Bucket=my-vm-exports,S3Prefix=exports/

aws ec2 describe-export-image-tasks --export-image-task-ids export-ami-0abcd1234example

The file lands at exports/export-ami-<id>.vmdk. Use VHD for Hyper-V or Xen, or RAW for KVM tooling.

What blocks an export is a short, specific list, and it is worth checking before you start:

• Windows, SQL Server, or any AMI created from an AWS Marketplace image.
• Encrypted EBS snapshots in the block device mapping.
• An AMI shared with you from another account.
• Volumes larger than 1 TiB, or EBS volumes attached after launch rather than in the mapping.
• A deleted base AMI, when exporting something launched from it.
• An export bucket using SSE-KMS encryption. SSE-S3 or unencrypted buckets work.

The Marketplace rule catches people more than any other. An instance launched from a Marketplace listing, including pre-built self-hosted software AMIs, cannot be exported, even after you have customised it.

Why imports fail

When a task ends in deleted with a StatusMessage, it is usually one of these:

• An unsupported kernel error means the kernel inside the image is not on the supported list for that distribution. Update the guest kernel and export again.
• Disk or partition errors usually mean an unsupported file system, or a VMDK that was not exported as stream-optimized. Re-export as OVA.
• Access denied on S3 almost always means the bucket is in a different region from the import, or the role policy names the wrong bucket.
• Images downloaded rather than installed. Cloud images from a vendor download page often fail the checks, which matches what we saw when this guide was first written. Install from the ISO inside the hypervisor and import that.
