Amazon Web Services (AWS)

Deepseek R1 - Developer Guide

Hiruna Kumara

• 8 min read
Deepseek R1 - Developer Guide

Welcome to the DeepSeek R1 Developer Guide for AWS integration! DeepSeek R1 is an advanced open-weight language model designed for deep reasoning, code generation, and complex problem-solving. Built with superior retrieval-augmented generation (RAG) capabilities and an optimized transformer architecture, it excels in tasks like logical reasoning, mathematical problem-solving, and multi-turn conversations. Let’s dive in and explore how to seamlessly integrate DeepSeek R1 into your AWS environment to unlock its full potential.

Prerequisites

Before you get started with the DeepSeek AMI, ensure you have the following prerequisites:

Launching the AMI

Step 1: Find and Select 'DeepSeek' AMI

  1. Log in to your AWS Management Console.
  2. Follow the provided links to access the 'DeepSeek' product you wish to set up. (Currently products are under review)
    a. Deepseek R1 7b
    b. Deepseek R1 70b

Step 2:  Initial Setup & Configuration

  1. Click the "Continue to Subscribe" button.
  2. After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
  3. Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
  4. Select the "CloudFormation Template for DeepSeek deployment" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
  5. From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

  1. Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

  1. Provide a unique "Stack name".
  2. Provide the "Admin Email" for SSL generation.
  3. For "DeploymentName", enter a name of your choice.
  4. Provide a public domain name for "DomainName". (DeepSeek will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
  5. Choose an instance type, "InstanceType" (Recommended: g4dn.xlarge).
  6. Select your preferred "keyName".
  7. Set "SSHLocation" as "0.0.0.0/0".
  8. Keep "SubnetCidrBlock" as "10.0.0.0/24".
  9. Keep "VpcCidrBlock" as "10.0.0.0/16".
  10. Click "Next".

Step3: Configure stack options

  1. Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
  2. click "Next".

Step4: Review

  1. Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

  1. Copy the public Ip labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

  1. Go to AWS Route 53 and navigate to "Hosted Zones".
  2. From there click on Create record.

3. Add record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access DeepSeek

You can access the DeepSeek application through the "DashboardUrl" or 'DashboardUrlIp' provided in the "Outputs" tab.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Generate SSL Manually

DeepSeek will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

  1. Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.

2. Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

  1. Open the terminal and go to the directory where your private key is located.
  2. Paste the following command into your terminal and press Enter: ssh -i <your key name> ubuntu@<Public IP address>.

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter and follow the instructions:

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Shutting Down DeepSeek

  1. Click the link labeled "DeepSeek" in the "Resources" tab to access the EC2 instance, you will be directed to the DeepSeek instance in EC2.

2. Select the DeepSeek instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove DeepSeek

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

API Documentation

1. Retrieve Completions

Retrieves completions based on the provided prompt.

  • Endpoint: /v1/completions
  • Method: POST
  • Request Body:
{
  "model": "deepseek-r1-7b",
  "prompt": "\n\n### Instructions:\nWhat is the capital of France?\n\n### Response:\n",
  "stop": [
    "\n",
    "###"
  ]
}
  • Response Body:
{
  "id": "cmpl-58878dfc-61d8-4818-9799-19cd2a957701",
  "object": "text_completion",
  "created": 1739388733,
  "model": "deepseek-r1-7b",
  "choices": [
    {
      "text": "The capital of France is Paris.",
      "index": 0,
      "logprobs": null,
      "finish_reason": "stop"
    }
  ],
  "usage": {
    "prompt_tokens": 15,
    "completion_tokens": 7,
    "total_tokens": 22
  }
}

2. Retrieve Embeddings

Please note that Embeddings method is currently not supported.

  • Endpoint: /v1/embeddings
  • Method: POST
  • Request Body:
{
  "input": "The food was delicious and the waiter...",
  "model": "deepseek-r1-7b"
}
  • Response Body: 500 Error
{
  "error": {
    "message": "Llama model must be created with embedding=True to call this method",
    "type": "internal_server_error",
    "param": null,
    "code": null
  }
}

3. Retrieve Chat Completions

Retrieves chat completions based on the provided chat messages.

  • Endpoint: /v1/chat/completions
  • Method: POST
  • Request Body:
{
  "model": "deepseek-r1-7b",
  "messages": [
    {
      "content": "You are a helpful assistant.",
      "role": "system"
    },
    {
      "content": "What is the capital of France?",
      "role": "user"
    }
  ],
  "stop": [
    "\n",
    "###"
  ]
}
  • Response Body:
{
  "id": "chatcmpl-e03153d7-0055-4c58-8b9c-14120748300e",
  "object": "chat.completion",
  "created": 1739388891,
  "model": "deepseek-r1-7b",
  "choices": [
    {
      "index": 0,
      "message": {
        "content": "The capital of France is Paris.",
        "role": "assistant"
      },
      "logprobs": null,
      "finish_reason": "stop"
    }
  ],
  "usage": {
    "prompt_tokens": 48,
    "completion_tokens": 12,
    "total_tokens": 60
  }
}

4. List Models

Retrieves a list of available models.

  • Endpoint: /v1/models
  • Method: GET
  • Response Body:
{
  "object": "list",
  "data": [
    {
      "id": "deepseek-r1-distill-qwen-7b",
      "object": "model",
      "owned_by": "me",
      "permissions": []
    }
  ]
}

5. Extras

There are new methods regarding tokenize and detokenize available. Feel free to use them as well.

Testing the API

  1. Create a directory
  2. Create 3 files (Full codes are given below)
    app.js
    package.json
    .env
  3. Run the following command
    npm install
  4. Edit variable file (.env)
  5. Run the following command
    npm start
  6. You will get the responses
const axios = require('axios');
require('dotenv').config();

const makePostRequest = async (url, data, timeout) => {
  try {
    const response = await axios.post(url, data, { timeout });
    return { success: response.status === 200, data: response.data };
  } catch (error) {
    return { success: false, error: error.message };
  }
};

const makeGetRequest = async (url, timeout) => {
  try {
    const response = await axios.get(url, { timeout });
    return { success: response.status === 200, data: response.data };
  } catch (error) {
    return { success: false, error: error.message };
  }
};

const printResponseData = (endpoint, data) => {
  console.log(`Response for ${endpoint}:`);
  console.log(JSON.stringify(data, null, 2));
  console.log('');
};

const checkEndpoints = async () => {
  const baseUrl = process.env.BASE_URL;
  const model = process.env.MODEL;

  const endpoints = [
    { path: '/completions', method: makePostRequest, data: { "model": model, "prompt": process.env.PROMPT1 }, printEnv: 'PRINT_COMPLETIONS_RESPONSE' },
    { path: '/embeddings', method: makePostRequest, data: { "input": process.env.PROMPT2, "model": model }, printEnv: 'PRINT_EMBEDDINGS_RESPONSE' },
    { path: '/chat/completions', method: makePostRequest, data: { "messages": [{ "content": "You are a helpful assistant.", "role": "system" }, { "content": process.env.PROMPT1, "role": "user" }], "model": model }, printEnv: 'PRINT_CHAT_COMPLETIONS_RESPONSE' },
    { path: '/models', method: makeGetRequest, printEnv: 'PRINT_MODELS_RESPONSE' }
  ];

  for (const endpoint of endpoints) {
    const url = `${baseUrl}${endpoint.path}`;
    const { success, data, error } = await endpoint.method(url, endpoint.method === makePostRequest ? endpoint.data : null, process.env.REQUEST_TIMEOUT || 50000);
    const printResponse = process.env[endpoint.printEnv] === 'true';

    if (success) {
      console.log(`*** Endpoint ${endpoint.path} is reachable.`);
      if (printResponse) {
        printResponseData(endpoint.path, data);
      }
      console.log('');
    } else {
      console.log(`*** Endpoint ${endpoint.path} is not reachable. Error:`, error);
    }
  }
};

checkEndpoints();
app.js
{
  "name": "test-llama",
  "version": "1.0.0",
  "description": "",
  "main": "index.js",
  "scripts": {
    "start": "node app.js",
    "test": "echo \"Error: no test specified\" && exit 1"
  },
  "author": "",
  "license": "ISC",
  "dependencies": {
    "axios": "^1.6.7",
    "dotenv": "^16.4.1"
  }
}
package.json
# Base URL for the API
BASE_URL=https://mixtral-test-prod.meetrix.io/v1

# Model to be used in requests
MODEL=mixtral-8x7b-instruct-v0.1

# Prompts for different endpoints
# /completions and /chat/completions
PROMPT1=What is the capital of France?
# /embeddings
PROMPT2=The food was delicious and the waiter...

# Whether to print responses for each endpoint
PRINT_COMPLETIONS_RESPONSE=true
PRINT_EMBEDDINGS_RESPONSE=false
PRINT_CHAT_COMPLETIONS_RESPONSE=true
PRINT_MODELS_RESPONSE=true

# Timeout for requests in milliseconds (default is 50000)
REQUEST_TIMEOUT=50000
.env

Check Server Logs

Step1: Log in to the server

  1. Open the terminal and go to the directory where your private key is located.
  2. Paste the following command into your terminal and press Enter:
    ssh -i <your key name> ubuntu@<Public IP address>

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo tail -f /var/log/syslog

Upgrades

When there is an upgrade, we will update the product with a newer version. You can check the product version in AWS Marketplace. If a newer version is available, you can remove the previous version and launch the product again using the newer version. Remember to backup the necessary server data before removing.

Troubleshoot

  1. If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2.  If you face the following error (do not have sufficient <instance_type> capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. If the llama service got stuck, you can follow the steps below

  • Log into the server (Find the steps in Check Server Logs section)
  • Run the below command.
sudo systemctl restart llama.service
  • Wait for several minutes and reload the dashboard URL.

5. Check whether the instance storage is full.

  • Log into the server and run the below command
df -h
root volume
  • If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.
  • Then reboot the instance and restart the llama service.

Conclusion

In conclusion, the DeepSeek R1 Developer Guide provides everything you need for a seamless integration of DeepSeek R1 into your AWS environment. Whether you're a beginner or an experienced developer, this guide offers clear, step-by-step instructions to ensure a smooth deployment. DeepSeek R1 excels in deep reasoning, code generation, and retrieval-augmented generation (RAG), making it a powerful tool for AI-driven applications. By leveraging its advanced capabilities, you can unlock new possibilities in AI development with efficiency and precision.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io)  for assistance with DeepSeek issues.
