Mistrallite - Developer Guide

Hiruna Kumara

Feb 8, 2024 • 8 min read

Welcome to the Meetrix Mistrallite Developer Guide! This guide is designed to assist you in seamlessly integrating Mistrallite into your AWS environment through detailed, step-by-step instructions.

Mistrallite is a fine-tuned model based on Mistral, with enhanced capabilities of processing long context (up to 32K tokens). This model is able to perform significantly better on several long context retrieve and answering tasks.

Video

Blog

https://meetrix.io/articles/how-to-install-mistrallite-ai-on-aws/

Prerequisites

Before you get started with the Mistrallite AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create g4dn type instances‌
‌(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select 'Mistrallite' AMI

Log in to your AWS Management Console.
Navigate to the 'Mistrallite' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation Template for Mistrallite deployment" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName". (Mistrallite will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: g4dn.xlarge).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
click "Next".

Step4: Review

Review and verify the details you've entered.‌

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".‌

‌

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.‌

Please wait for 5-10 minutes until the stack has been successfully created.‌

Update DNS

Step1: Copy IP Address

Copy the public Ip labeled "PublicIp" in the "Outputs" tab.‌

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, select the domain you provided to "DomainName".‌

3. Click "Edit record" in the "Record details" and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Mistrallite

You can access the Mistrallite application through the "DashboardUrl" or 'DashboardUrlIp' provided in the "Outputs" tab.‌

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)‌

Generate SSL Manually

Mistrallite will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.

2. Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.‌

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter: ssh -i <your key name> ubuntu@<Public IP address>.‌

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter and follow the instructions:

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Shutting Down Mistrallite

Click the link labeled "Mistrallite" in the "Resources" tab to access the EC2 instance, you will be directed to the Mistrallite instance in EC2.‌

2. Select the Mistrallite instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".‌

Remove Mistrallite

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

API Documentation

1. Retrieve Completions

Retrieves completions based on the provided prompt.

Endpoint: /v1/completions
Method: POST
Request Body:‌

{
  "prompt": "\n\n### Instructions:\nWhat is the capital of France?\n\n### Response:\n",
  "stop": [
    "\n",
    "###"
  ]
}

json

‌
Response Body:‌

{
  "id": "cmpl-d41a8169-0d27-4466-8f0f-6b2a1a4b2585",
  "object": "text_completion",
  "created": 1703229756,
  "model": "/root/models/mistrallite.Q5_K_M.gguf",
  "choices": [
    {
      "text": "The capital of France is Paris.",
      "index": 0,
      "logprobs": null,
      "finish_reason": "stop"
    }
  ],
  "usage": {
    "prompt_tokens": 22,
    "completion_tokens": 7,
    "total_tokens": 29
  }
}

json

2. Retrieve Embeddings

Retrieves embeddings based on the provided input text.

Endpoint: /v1/embeddings
Method: POST
Request Body:‌

{
  "input": "The food was delicious and the waiter..."
}

json

‌
Response Body:‌

{
    "object": "list",
    "data": [
        {
            "object": "embedding",
            "embedding": [
            	-0.07521496713161469,
                0.44098934531211853,
                0.6786724328994751,
                ...
            ],
            "index": 0
        }
    ],
    "model": "/root/models/mistrallite.Q5_K_M.gguf",
    "usage": {
        "prompt_tokens": 10,
        "total_tokens": 10
    }
}

json

3. Retrieve Chat Completions

Retrieves chat completions based on the provided chat messages.

Endpoint: /v1/chat/completions
Method: POST
Request Body:‌

{
  "messages": [
    {
      "content": "You are a helpful assistant.",
      "role": "system"
    },
    {
      "content": "What is the capital of France?",
      "role": "user"
    }
  ]
}

json

‌
Response Body:‌

{
  "id": "chatcmpl-c53b0059-acf0-4533-b6a1-55e520578320",
  "object": "chat.completion",
  "created": 1703230000,
  "model": "/root/models/mistrallite.Q5_K_M.gguf",
  "choices": [
    {
      "index": 0,
      "message": {
        "content": " The capital of France is Paris. Paris is one of the most popular and visited cities in the world, known for its beautiful architecture, art museums, fashion, and delicious food. It is also home to many iconic landmarks such as the Eiffel Tower, Louvre Museum, Notre-Dame Cathedral, and more. If you have any questions about France or Paris, I'd be happy to try and help answer them for you!",
        "role": "assistant"
      },
      "finish_reason": "stop"
    }
  ],
  "usage": {
    "prompt_tokens": 31,
    "completion_tokens": 94,
    "total_tokens": 125
  }
}

json

4. List Models

Retrieves a list of available models.

Endpoint: /v1/models
Method: GET
Response Body:‌

{
  "object": "list",
  "data": [
    {
      "id": "/root/models/mixtral-8x7b-instruct-v0.1.Q4_K_M.gguf",
      "object": "model",
      "owned_by": "me",
      "permissions": []
    }
  ]
}

json

Testing the API

Create a directory
Create 3 files (Full codes are given below)‌
‌app.js‌
‌package.json‌
‌.env
Run the following command‌
‌npm install
Edit variable file (.env)
Run the following command‌
‌npm start
You will get the responses‌

const axios = require('axios');
require('dotenv').config();

const makePostRequest = async (url, data, timeout) => {
  try {
    const response = await axios.post(url, data, { timeout });
    return { success: response.status === 200, data: response.data };
  } catch (error) {
    return { success: false, error: error.message };
  }
};

const makeGetRequest = async (url, timeout) => {
  try {
    const response = await axios.get(url, { timeout });
    return { success: response.status === 200, data: response.data };
  } catch (error) {
    return { success: false, error: error.message };
  }
};

const printResponseData = (endpoint, data) => {
  console.log(`Response for ${endpoint}:`);
  console.log(JSON.stringify(data, null, 2));
  console.log('');
};

const checkEndpoints = async () => {
  const baseUrl = process.env.BASE_URL;
  const model = process.env.MODEL;

  const endpoints = [
    { path: '/completions', method: makePostRequest, data: { "model": model, "prompt": process.env.PROMPT1 }, printEnv: 'PRINT_COMPLETIONS_RESPONSE' },
    { path: '/embeddings', method: makePostRequest, data: { "input": process.env.PROMPT2, "model": model }, printEnv: 'PRINT_EMBEDDINGS_RESPONSE' },
    { path: '/chat/completions', method: makePostRequest, data: { "messages": [{ "content": "You are a helpful assistant.", "role": "system" }, { "content": process.env.PROMPT1, "role": "user" }], "model": model }, printEnv: 'PRINT_CHAT_COMPLETIONS_RESPONSE' },
    { path: '/models', method: makeGetRequest, printEnv: 'PRINT_MODELS_RESPONSE' }
  ];

  for (const endpoint of endpoints) {
    const url = `${baseUrl}${endpoint.path}`;
    const { success, data, error } = await endpoint.method(url, endpoint.method === makePostRequest ? endpoint.data : null, process.env.REQUEST_TIMEOUT || 50000);
    const printResponse = process.env[endpoint.printEnv] === 'true';

    if (success) {
      console.log(`*** Endpoint ${endpoint.path} is reachable.`);
      if (printResponse) {
        printResponseData(endpoint.path, data);
      }
      console.log('');
    } else {
      console.log(`*** Endpoint ${endpoint.path} is not reachable. Error:`, error);
    }
  }
};

checkEndpoints();

javascript

app.js

‌‌

{
  "name": "test-llama",
  "version": "1.0.0",
  "description": "",
  "main": "index.js",
  "scripts": {
    "start": "node app.js",
    "test": "echo \"Error: no test specified\" && exit 1"
  },
  "author": "",
  "license": "ISC",
  "dependencies": {
    "axios": "^1.6.7",
    "dotenv": "^16.4.1"
  }
}

json

package.json

‌‌

# Base URL for the API
BASE_URL=https://mixtral-test-prod.meetrix.io/v1

# Model to be used in requests
MODEL=mixtral-8x7b-instruct-v0.1

# Prompts for different endpoints
# /completions and /chat/completions
PROMPT1=What is the capital of France?
# /embeddings
PROMPT2=The food was delicious and the waiter...

# Whether to print responses for each endpoint
PRINT_COMPLETIONS_RESPONSE=true
PRINT_EMBEDDINGS_RESPONSE=false
PRINT_CHAT_COMPLETIONS_RESPONSE=true
PRINT_MODELS_RESPONSE=true

# Timeout for requests in milliseconds (default is 50000)
REQUEST_TIMEOUT=50000

.env

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter: ‌
‌ssh -i <your key name> ubuntu@<Public IP address>‌

‌

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo tail -f /var/log/syslog

Upgrades

When there is an upgrade, we will update the product with a newer version. You can check the product version in AWS Marketplace. If a newer version is available, you can remove the previous version and launch the product again using the newer version. Remember to backup the necessary server data before removing.

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.‌

‌

2. If you face the following error (do not have sufficient <instance_type> capacity...) while creating the stack, try changing the region or try creating the stack at a later time.‌

‌

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.‌

‌

Conclusion

In conclusion, the Meetrix Mistrallite Developer Guide is your essential resource for seamlessly integrating advanced capabilities into your AWS environment. Mistrallite's improved model, which is based on Mistral, performs better by analyzing longer contexts. With Mistrallite's seamless connection, you can confidently elevate your AI apps and have access to cutting-edge features and efficiency in the artificial intelligence space.

Technical Support

Reach out to Meetrix Support (support@meetrix.io) for assistance with Mistrallite issues.
