OpenClaw - Developer Guide

Hiruna Kumara — Fri, 27 Mar 2026 16:36:16 GMT

Welcome to the OpenClaw AWS Deployment Guide. Integrate OpenClaw with AWS for seamless, automated operations. Empower teams with real-time collaboration and workflow orchestration in trusted, enterprise-ready environments. Let’s dive in.

Prerequisites

Before you get started with the OpenClaw AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create an instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''OpenClaw '' AMI

Log in to your AWS Management Console.
Navigate to the 'OpenClaw' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy OpenClaw " as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".
Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
Enter AdminUsername and AdminPassword for the openclaw dashboard. Please save the credentials.
Keep the AmiId as default.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (OpenClaw will automatically try to setup SSL based on provided domain name, if its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.large).
Select your preferred "keyName".
Now add the OpenclawApiKey and the OpenclawProvider of the key.
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones". Click on the correct hosted zone.
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access OpenClaw

You can setup the OpenClaw application through the "DashboardUrl" or "DashboardUrlIp" provided in the "Outputs" tab.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Enter the Admin Username and Password you previously entered.

Then you will be redirected to the dashboard.

You may also access the dashboard through the domain.

Add Channels

Create a telegram bot and get the token (Please refer to the official documentations for this).
Replace the "paste-token-here" with the token.

{
  "channels": {
    "telegram": {
      "enabled": true,
      "botToken": "paste-token-here",
      "dmPolicy": "pairing",
      "groups": {
        "*": {
          "requireMention": true
        }
      }
    }
  }
}

3. Go to Config in OpenClaw dashboard and select the Raw mode.

4. Click on reveal sensitive values.

5. Paste the above lines after the "update" part in the JSON file and click on save.

6. You have to wait several minutes while the service restarts.

7. Now you can configure the AI agent to work with the telegram bot.

Generate SSL Manually

Step1: Copy IP Address

OpenClaw will automatically try to setup SSL, if its unsuccessful then you have to setup SSL manually.

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@.

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter and follow the instructions:

sudo /root/certificate_generate_standalone.sh

Admin Email is needed to generate SSL certificates.

Check Server Logs

OpenClaw runs as a systemd user service. Use the commands below to diagnose issues.

1. OpenClaw Gateway Logs

Check the status of the OpenClaw gateway service:

systemctl --user status openclaw-gateway

View live logs (follow mode):

journalctl --user -u openclaw-gateway -f

View recent logs (last 100 lines):

journalctl --user -u openclaw-gateway -n 100

2. Nginx Logs

Check nginx access and error logs:

sudo tail -f /var/log/nginx/access.log
sudo tail -f /var/log/nginx/error.log

If you see 502 Bad Gateway errors, the OpenClaw gateway is not running. Restart it with:

systemctl --user restart openclaw-gateway

3. Channel Logs (Telegram, Discord, etc.)

If you have messaging channels configured, view their logs with:

openclaw channels logs

4. Restarting the Service

If the gateway is unresponsive or you have updated the configuration:

systemctl --user restart openclaw-gateway

Shutting Down OpenClaw

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the OpenClaw instance in EC2.

2. Select the OpenClaw instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove OpenClaw

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

When there is an upgrade, we will update the product with a newer version. You can check the product version in AWS Marketplace. If a newer version is available, you can remove the previous version and launch the product again using the newer version. Remember to backup the necessary server data before removing.

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.

Conclusion

The Meetrix Openclaw Deployment Guide is your definitive resource for launching Openclaw on AWS with ease. Designed for developers, DevOps engineers, and IT teams, it provides clear, step-by-step instructions to achieve a secure, scalable, and efficient deployment. Openclaw is a powerful AI application platform that enables organizations to build, manage, and scale AI-driven workflows and agents. Using this guide, you can unlock Openclaw's full potential, allowing your team to rapidly deploy AI solutions, streamline operations, and create flexible, production-ready systems that evolve with your needs.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with OpenClaw issues.

NocoBase - Developer Guide

Maneesha Shehara — Thu, 04 Sep 2025 01:54:50 GMT

Welcome to the NocoBase AWS Deployment Guide. Integrate NocoBase with AWS for seamless, automated operations. Empower teams with real-time collaboration and workflow orchestration in trusted, enterprise-ready environments. Let’s dive in.

Prerequisites

Before you get started with the NocoBase AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create an instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''NocoBase '' AMI

Log in to your AWS Management Console.
Navigate to the 'NocoBase ' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy NocoBase " as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".
Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (NocoBase will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.small).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access NocoBase

You can setup the NocoBase application through the "DashboardUrl" or "DashboardUrlIp" provided in the "Outputs" tab. This will allow you to create an Admin account and all the future accounts will be created through the Admin panel.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Important: During stack creation, you will be prompted to create the NocoBase Dashboard Email for your NocoBase deployment. The email address and password you enter at this stage will be used to manage your entire workspace . Choose a strong password and store your credentials securely, as they are essential for future access and ongoing team management.

Generate SSL Manually

Step1: Copy IP Address

NocoBase will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@.

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter and follow the instructions:

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo docker ps

Select the correct container and check logs

sudo docker logs 0b
sudo docker logs a5

Shutting Down NocoBase

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the NocoBase instance in EC2.

2. Select the NocoBase instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove NocoBase

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.

Conclusion

The Meetrix NocoBase Deployment Guide is your definitive resource for integrating NocoBase into AWS with ease. Designed for DevOps engineers, system administrators, and IT leaders, it offers clear, step-by-step instructions to achieve a secure and scalable deployment. NocoBase is a robust open-source platform that empowers teams in high-trust environments with real-time collaboration, automation, and flexible integrations. Using this guide, you can unlock NocoBase’s full potential, enabling your organization to create efficient, secure, and self-hosted communication systems that grow with your needs.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with NocoBase issues.

TimescaleDB - Developer Guide

Maneesha Shehara — Tue, 19 Aug 2025 01:28:27 GMT

Welcome to the TimescaleDB AWS Deployment Guide. Seamlessly integrate TimescaleDB with AWS for scalable, secure, and automated operations. Gain the expertise to install and configure these tools using our step-by-step AWS deployment guide:

TimescaleDB - A powerful PostgreSQL-based time-series database, optimized for handling high ingestion and analytics workloads.
Prometheus - A leading open-source monitoring and alerting toolkit for collecting real-time metrics.
Grafana - A visualization and analytics platform for creating dynamic dashboards and insightful reports.
Node Exporter - A lightweight exporter that provides detailed Linux host metrics to Prometheus.

This in-depth resource covers everything from provisioning your AWS environment to securely deploying and optimizing your stack for scalability, high availability, and performance. Whether you're building a DevOps observability hub, a performance analytics system, or a secure team collaboration dashboard, our guide ensures you can deploy this monitoring and analytics stack efficiently and effectively within your AWS infrastructure.

Prerequisites

Before you get started with the TimescaleDB AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''TimescaleDB'' AMI

Log in to your AWS Management Console.
Navigate to the 'TimescaleDB' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy TimescaleDB " as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Choose an instance type, "InstanceType" (Recommended: m6i.large).
Enter your TimescaleDB Dashboard “Grafana Dashboard Password”
Enter your TimescaleDB Dashboard “Grafana Dashboard Username”
Enter your Grafana Domain Name “Grafana Domain Name”
Enter your Prometheus Dashboard “Prometheus Domain Name”
Enter your TimescaleDB Dashboard “TimescaleDB Database Password”
Enter your TimescaleDB Dashboard “TimescaleDB Database Username”
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Prometheus and Grafana

Once the deployment is complete, you can access your monitoring tools through the URLs provided in the Outputs tab of your AWS stack:

Grafana Dashboard – Use this link to log in, create your Admin account, and configure dashboards. All future user accounts can be managed through the Grafana Admin panel.

Prometheus Dashboard – Access this link to view collected metrics, run queries, and monitor system performance in real time.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Please enter the Grafana Dashboard Username and Grafana Dashboard

Password that you have provided. Ensure both are stored securely for future reference

Generate SSL Manually

TimescaleDB will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter, and follow the instructions

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo docker ps

Select the correct container and check logs

sudo docker logs 85

Shutting Down TimescaleDB

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the TimescaleDB instance in EC2.

2. Select the TimescaleDB instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove TimescaleDB

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.

Conclusion

The Meetrix TimescaleDB Deployment Guide offers step-by-step instructions to help you securely and seamlessly deploy TimescaleDB on AWS. Designed for DevOps engineers, system administrators, and IT leaders, this guide empowers your team to build a scalable, self-hosted communication platform. Unlock real-time collaboration, automation, and integration capabilities tailored for high-trust environments all with clarity and confidence.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with TimescaleDB issues.

Appsmith- Developer Guide

Maneesha Shehara — Mon, 11 Aug 2025 06:28:41 GMT

Appsmith is an open-source low-code platform designed for building internal tools, admin panels, dashboards, and workflows. With Appsmith, you can rapidly create full-featured apps by connecting to APIs, databases, and third-party services all with minimal coding. It provides a drag-and-drop UI builder, pre-built widgets, and easy integration with REST APIs, GraphQL, and SQL queries. This guide provides step-by-step instructions to help you seamlessly integrate Appsmith into your development projects.

Prerequisites

Before you get started with the Appsmith AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''Appsmith'' AMI

Log in to your AWS Management Console.
Navigate to the 'Appsmith' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy appsmith" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (the custom domain is configured through the Admin Settings Custom Domain section in the Appsmith UI)
Choose an instance type, "InstanceType" (Recommended: t3.large).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Appsmith

You can setup the Appsmith application through the "DashboardUrlIp" provided in the "Outputs" tab. This will allow you to create an Admin account and all the future accounts will be created through the Admin panel.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Please wait until Appsmith is ready. This may take a few minutes.

Generate SSL Manually

After the initial setup, the custom domain is configured through the Admin Settings Custom Domain section in the Appsmith UI.

Settings → Instance settings → Custom Domain section

Click “save and restart”

Appsmith is now accessible via the domain.

Shutting Down Appsmith

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the Appsmith instance in EC2.

2. Select the Appsmith instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove Appsmith

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Conclusion

The Meetrix Appsmith Developer Guide is your ultimate resource for seamlessly integrating Appsmith into your projects. Whether you're an experienced developer or new to internal tool building, our guide provides clear, step-by-step instructions for a smooth setup process. Appsmith is a powerful and intuitive open-source platform for rapidly creating custom internal applications, connecting to APIs, and integrating with databases without heavy coding overhead. With the Meetrix Appsmith Developer Guide, you'll confidently harness Appsmith’s capabilities, enabling you to build modern, dynamic web applications and dashboards with ease.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with Appsmith issues.

Launch Grafana on AWS with Meetrix - Pre-Configured Dashboard AMI for Instant Monitoring and Insights

Shalomi Umeshika — Tue, 05 Aug 2025 06:06:35 GMT

Deploy fully configured Grafana in minutes with secure setup, seamless integration, and 24/7 expert support

In today’s data-driven world, real-time visibility into your infrastructure, applications, and services is essential. Whether you're monitoring servers, Kubernetes clusters, cloud services, or business KPIs, Grafana is the go-to solution trusted by millions of developers, SREs, and enterprises worldwide.

With the Meetrix Grafana AMI, you can deploy a production-ready Grafana dashboard server in your AWS account in just a few clicks, optimized for speed, security, and scale.

What Is Grafana?

Grafana is an open-source analytics and visualization platform that turns metrics, logs, and traces into powerful, interactive dashboards.

Core Features:

Custom dashboards for real-time monitoring
Support for Prometheus, Loki, InfluxDB, Elasticsearch, PostgreSQL, and more
Alerting and notification integrations (Slack, PagerDuty, email)
Role-based access controls (RBAC) and secure sharing
Plugin ecosystem for data sources, panels, and themes
Multi-tenant support for enterprise-grade environments

Grafana gives you one unified window into your system health, performance, and reliability in a way that’s clear, flexible, and powerful.

Why Use the Meetrix Grafana AMI?

While Grafana is open source and easy to download, setting it up properly in a secure, scalable AWS environment can be time-consuming. You’ll need to handle server provisioning, user authentication, SSL certificates, firewall rules, data source integrations, and ongoing maintenance.

The Meetrix Grafana AMI eliminates all of that complexity.

Included in the Meetrix AMI:

Latest stable Grafana version, fully installed
NGINX reverse proxy with SSL enabled
Pre-configured IAM roles and security groups
Optional setup for Prometheus, Loki, or custom data sources
System-level hardening for production use
24/7 expert support and consulting services

Who Should Use This?

This AMI is ideal for:

DevOps and SRE teams needing unified monitoring tools
IT operations teams managing distributed systems or multi-cloud environments
Engineering leads who want real-time visibility into app and service health
Startups and enterprises that need scalable, secure dashboards
Agencies or MSPs who deploy Grafana for multiple clients

Popular Use Cases

Use Case	Description
Kubernetes cluster monitoring	Visualize node metrics, pod health, and service uptime
Application performance	Track latency, throughput, and error rates using Prometheus
Infrastructure analytics	Combine logs, metrics, and traces from multiple sources
Business dashboards	Display KPIs and analytics from PostgreSQL or MySQL
DevSecOps visualization	Monitor audit logs, security scans, and intrusion attempts

Benefits of Meetrix's Grafana AMI

Feature	Meetrix Grafana AMI	Manual Setup
Setup Time	< 10 minutes	Hours to days
HTTPS & SSL	Pre-installed and configured	Requires manual configuration
Security	IAM roles, firewall best practices	Must be configured manually
Data Source Integration	Optional pre-wiring available	Must configure manually
Support	24/7 human expert support	Community-based only
Optional Scaling & Consulting	Available	Not included

Frequently Asked Questions

Can I add my own data sources?
Yes. Grafana supports dozens of data sources natively, and Meetrix can assist with pre-wiring them into your deployment.

Is this secure for enterprise use?
Yes. Our AMI includes hardened server configuration, HTTPS, and strict IAM access policies.

Does this include alerting features?
Yes. Grafana’s alerting system is fully available, and we can help configure integrations like Slack, Opsgenie, and PagerDuty.Can I deploy this in a private subnet?
Yes. The AMI is VPC-ready and works in both public and private network setups

Monitor Everything, Anywhere with Grafana by Meetrix on AWS

Grafana gives you the power to visualize and analyze your data in real time. With Meetrix’s Grafana Dashboard AMI, you can skip the hassle of setup and go straight to building beautiful, actionable dashboards, secured, supported, and deployed in minutes.

Whether you're a startup building your first DevOps stack or an enterprise needing high-availability observability, Meetrix helps you deploy Grafana faster and smarter.

Launch your Grafana monitoring stack on AWS with Meetrix, and take control of your infrastructure visibility.

Get Started with Grafana AMI by Meetrix on AWS Marketplace

Deploy OpenWebUI with Ollama on AWS using Meetrix: Secure, Intuitive UI for Self-Hosted LLMs

Shalomi Umeshika — Tue, 05 Aug 2025 06:06:21 GMT

Launch your private AI assistant with OpenWebUI and Ollama in minutes, fully configured, secure, and optimized by Meetrix on AWS

As demand for self-hosted large language models (LLMs) grows, organizations are looking for intuitive tools that allow private, flexible, and high-performance deployments. OpenWebUI, integrated with Ollama, provides a powerful, user-friendly interface and a backend that simplifies running and managing open-source LLMs directly in your infrastructure.

Meetrix now brings this setup to the AWS Marketplace with a pre-configured OpenWebUI + Ollama AMI, offering production-grade performance, hardened security, and 24/7 support.

What Are OpenWebUI and Ollama?

OpenWebUI

OpenWebUI (formerly Oobabooga UI) is a browser-based interface that enables seamless interaction with self-hosted LLMs. It includes chat-based workflows, multi-model support, persona control, and prompt history in a user-friendly format.

Ollama

Ollama is a lightweight model runner designed to make local LLM deployment simple. It manages downloads, tokenization, execution, and compatibility with a wide range of open-source models.

Together, OpenWebUI and Ollama offer a secure and developer-friendly AI interface for managing and interacting with models within your own environment.

Why Choose Meetrix for AWS Deployment?

Manually setting up OpenWebUI with Ollama can be complex and time-consuming. Meetrix simplifies the entire process with a production-ready AMI that includes:

Pre-installed and fully integrated OpenWebUI and Ollama
Support for a variety of open-source models including LLaMA, Mistral, and Gemma
Secured access with HTTPS and IAM compatibility
VPC-ready configuration for isolated environments
24/7 support and deployment assistance

Ideal Use Cases

Use Case	Description
Lightweight AI assistant demos	Deploy private LLM chat interfaces for internal teams
LLM prototyping and development	Explore prompt designs and workflows in a local environment
Educational and research tools	Use AI safely in classrooms, labs, or training centers
Secure Q&A and document tools	Build small-scale retrieval systems with private data
Internal productivity assistants	Create specialized copilots for enterprise knowledge and workflows

Who Should Use This?

This OpenWebUI + Ollama AMI is ideal for:

Developers building LLM-powered applications
Startups prototyping AI features
Research institutions exploring open models
Privacy-conscious teams deploying AI in-house
Organizations avoiding third-party model APIs

Benefits of Meetrix’s OpenWebUI and Ollama AMI

Feature	Meetrix AMI	Manual Setup
Setup Time	Under 10 minutes	Requires multiple installation steps
Model Compatibility	Ready for GGUF, GPTQ, and more	Manual configuration required
Security Configuration	HTTPS, IAM, VPC ready	DIY security setup
Interface Usability	Pre-tuned for ease of use	Varies by environment
Support	24/7 from Meetrix experts	None or community-only

Frequently Asked Questions

Which models are supported with Ollama?
OpenWebUI with Ollama supports popular open models such as LLaMA, Mistral, Gemma, and various GGUF or GPTQ-based variants.

Do I need technical experience to deploy this?
No. Meetrix provides a fully configured AMI and guidance to help you launch and run it easily.

Can I use this in a private VPC?
Yes. It is fully compatible with AWS VPC configurations and can run in isolated environments.

Can I extend the UI with plugins?
Yes. OpenWebUI supports custom plugins and extensions for chat, formatting, and workflow enhancements.

What kind of support is included?
We offer full technical assistance for deployment, configuration, and customization with 24/7 availability.

Self-Hosted AI, Simplified with OpenWebUI and Ollama by Meetrix

OpenWebUI and Ollama offer a powerful combination for teams that need intuitive, secure access to self-hosted LLMs. Meetrix enhances this experience with an AWS-optimized deployment that ensures speed, security, and simplicity.

Whether you're launching a prototype, building internal AI tools, or enabling private model access across your organization, Meetrix delivers a fast and reliable solution.

Launch your private LLM interface today with OpenWebUI and Ollama by Meetrix on AWS Marketplace.

Deploy Apache NiFi on AWS with Meetrix - Simplify Complex Data Flows in Minutes

Shalomi Umeshika — Mon, 04 Aug 2025 08:05:45 GMT

Pre-configured, production-ready NiFi environments backed by 24/7 expert support

In today's data-driven world, the ability to collect, route, transform, and monitor data in real-time is mission-critical. Whether you're streaming logs from remote IoT sensors, processing patient records securely, or integrating financial transactions across systems, data flow orchestration is the foundation of your infrastructure.

That’s why teams are turning to Apache NiFi, the powerful open-source data flow platform and now, with Meetrix’s Apache NiFi AMI on AWS Marketplace, you can deploy it in minutes, fully configured and enterprise-ready.

What Is Apache NiFi?

Apache NiFi is a robust, open-source data integration tool designed to automate the movement and transformation of data across systems. Originally developed by the NSA and now maintained by the Apache Software Foundation, NiFi enables:

Visual flow design with a drag-and-drop interface
Real-time data ingestion from virtually any source (databases, sensors, APIs, streams)
Routing, filtering, transforming, and enriching data on the fly
Secure data transfers with end-to-end traceability
Built-in support for back pressure, prioritization, and load balancing

Why Use Meetrix to Deploy Apache NiFi?

While NiFi is powerful, installing and configuring it for production, especially with security, clustering, and cloud integrations, can be complex.

Meetrix simplifies the entire process with a secure, pre-configured AWS AMI that gets your NiFi instance running in minutes, not days.

What You Get with Meetrix’s Apache NiFi AMI:

One-click AWS deployment
Pre-secured environment (SSL, authentication, and IAM-ready)
Optimized settings for production-scale throughput
Support for clustering, processors, and remote process groups
24/7 expert support for setup, tuning, scaling, and custom integrations

Who Is This For?

Apache NiFi by Meetrix is purpose-built for:

1. Data Engineers

Automate pipelines for ETL, ELT, and stream processing
Visually manage transformations and schema evolution

2. DevOps & Platform Engineers

Orchestrate secure data flows between services and environments
Monitor flow health, errors, and bottlenecks in real-time

3. IT Architects & System Integrators

Implement enterprise-wide data routing between legacy and cloud systems
Standardize governance and compliance for sensitive data

Market Segments & Industries

Segment	Use Cases
Data Engineering	ETL pipelines, batch/stream integration, data lake ingestion
IoT & Edge	Ingest and process data from sensors, gateways, and field devices
Cybersecurity	Capture and route logs, threat intelligence feeds, and alerts
Healthcare	Integrate HL7/FHIR data, anonymize PHI, and route lab records
Financial Services	Transaction monitoring, fraud detection, and audit trail capture
Retail & E-commerce	Customer behaviour tracking, real-time inventory updates

Top Use Cases with Apache NiFi

Log aggregation and stream enrichment
IoT pipeline orchestration (from devices to analytics platforms)
Cloud-to-cloud data migration and syncing
Real-time alerting from security event streams
Automated processing of HL7, CSV, JSON, XML, and Avro data
Feeding machine learning pipelines with clean, labelled data
Data provenance and audit logging for compliance

Why Choose Meetrix?

Feature	Meetrix Apache NiFi AMI	DIY Installation
Setup Time	< 10 minutes	Several hours or days
Security	Pre-hardened and SSL-ready	Must configure manually
Scalability	Cluster-ready configurations	Requires tuning
Updates & Maintenance	Managed by experts	Self-managed
Support	24/7 expert technical support	Community only
Optional Consulting	Available	Not applicable

FAQs

Is Apache NiFi open source?
Yes, NiFi is free and open-source. With Meetrix, you're paying only for infrastructure and optional support to simplify deployment.

Can I run NiFi in a cluster?
Yes. Meetrix can help you configure and launch NiFi in a clustered mode for high availability and throughput.

Is this secure for production?
Absolutely. We pre-configure SSL, port restrictions, and IAM best practices to help you launch safely in your AWS environment.

Do I need to configure anything after launch?
Basic flows can run immediately. Advanced configurations, integrations, and clustering can be customized as needed, with our help if required.

Control Your Data Flows with Confidence

Today’s applications, from fraud detection to real-time IoT analytics, demand data that’s fast, secure, and intelligently routed. Apache NiFi gives you the visual control and processing power to manage that complexity.

But why start from scratch?

With Meetrix’s Apache NiFi AMI, you get a hardened, production-ready NiFi setup on AWS, backed by experts who understand the challenges of data engineering, security, and scalability.

So you can stop debugging YAML files and start building smarter pipelines today.
Deploy Apache NiFi by Meetrix on AWS Marketplace

Deploy Directus on AWS with Meetrix -The Open-Source Headless CMS, Pre-Configured and Production-Ready

Shalomi Umeshika — Mon, 04 Aug 2025 07:53:27 GMT

Launch your own self-hosted Directus instance in minutes, fully secured, scalable, and backed by 24/7 expert support

Modern digital products demand flexibility, speed, and control over content and data infrastructure. Whether you're building websites, mobile apps, dashboards, or digital experiences, a traditional CMS often falls short.

That’s where Directus comes in: a modern, open-source headless CMS and data platform that works seamlessly with your existing SQL database.

With Meetrix’s Directus AMI on AWS, you can deploy a ready-to-use, fully configured Directus environment in just a few clicks, no manual installation, no DevOps overhead.

What Is Directus?

Directus is an open-source platform that transforms any SQL database into a powerful headless CMS and API. Unlike traditional CMS platforms, Directus does not store your data; it simply wraps your existing schema with a dynamic API and user-friendly admin interface.

Key Features:

No lock-in: Use your own database schema
REST and GraphQL APIs auto-generated from your tables
Clean admin app with role-based access controls
Extensible with custom hooks, endpoints, and plugins
File management, dashboards, insights, and more
Built for developers and non-technical users alike

Directus gives teams full control of their backend content and data workflows, without the rigidity of legacy CMS tools.

Why Use the Meetrix Directus AMI?

Deploying Directus manually involves provisioning infrastructure, configuring web servers, setting up databases, managing SSL, and handling updates. It can take hours and require specialized expertise.

The Meetrix Directus AMI removes that friction with a fully optimized, secure, and scalable AWS deployment.

Meetrix Directus AMI includes:

Pre-installed Directus (latest stable version)
PostgreSQL or MySQL backend configuration
NGINX web server and HTTPS/SSL setup
IAM-compatible and firewall-hardened deployment
Secure admin access and production-ready settings
24/7 expert support and infrastructure consulting

Who Should Use This?

Meetrix’s Directus AMI is ideal for:

Frontend developers looking for a clean, powerful CMS backend
Digital product teams building websites, apps, and internal tools
Startups deploying content-driven experiences without SaaS lock-in
Agencies managing CMS deployments for multiple clients
Enterprises that need customizable, secure, and compliant CMS solutions
Open data projects and public dashboards built on SQL

Use Cases by Industry

Industry	Use Case Examples
SaaS Platforms	Custom admin portals, user-generated content APIs
Media & Publishing	Editorial workflows, content APIs, video/image asset management
E-commerce	Product catalogs, inventory APIs, dynamic content admin
Government	Open data portals, structured content publishing
Healthcare	Internal dashboards, knowledge bases, HIPAA-compliant deployment
Education	Course content delivery, admin tools, multilingual site backends

Why Choose Meetrix?

Feature	Meetrix Directus AMI	Manual Installation
Setup Time	< 10 minutes	Hours or days
Security	SSL, IAM, firewall pre-configured	Must configure from scratch
Database Integration	Pre-wired with PostgreSQL/MySQL	Requires additional steps
Updates & Maintenance	Supported by experts	DIY
Scalability	AWS-native, optimized	Must configure manually
Support	24/7 human support	Community forums only

Frequently Asked Questions

Does this support PostgreSQL and MySQL?
Yes. You can use either database and we provide guidance for migrating your schema.

Can I use this in a private subnet or VPC?
Absolutely. The AMI supports full VPC integration, internal access, and network-level restrictions.

Is Directus secure for production use?
Yes. We configure HTTPS, firewall rules, and access controls by default. Admin access is secured.

Can I extend Directus with custom code?
Yes. Directus is fully extensible via hooks, endpoints, and custom modules.

Is support included in the AMI pricing?
Yes. All Meetrix Directus AMIs include 24/7 support. Optional consulting is also available.

Build Flexible, Future-Ready Apps with Directus and Meetrix

Content and data management shouldn’t be limited by legacy tools or rigid CMS platforms. With Directus, you gain the flexibility of a modern, open-source headless CMS, and with Meetrix, you get a production-ready environment, launched in minutes and fully supported.

Whether you're building a custom API, internal dashboard, or scalable content system, the Directus AMI by Meetrix helps you get there faster, securely, reliably, and with expert support at every step.

Launch Directus on AWS with Meetrix. Power your content your way.

Get Started with Directus by Meetrix on AWS Marketplace

Grafana - Developer Guide

Maneesha Shehara — Tue, 29 Jul 2025 05:04:47 GMT

Welcome to the Grafana Deployment Guide for AWS Integration! Grafana is the open-source observability and analytics platform built for reliability and performance in high-trust environments. Seamlessly deploy Grafana within your AWS infrastructure to enable real-time dashboards, scalable monitoring, and secure data visualization at enterprise scale.

Empower your DevOps teams with unified metrics, logs, and traces across AWS services. Automate alerting, optimize infrastructure performance, and extend Grafana with powerful plugins, all while maintaining full control over your data.

Let’s get started and elevate your cloud monitoring and operational excellence with Grafana on AWS.

Prerequisites

Before you get started with the Grafana AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''Grafana'' AMI

Log in to your AWS Management Console.
Navigate to the 'Grafana' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy Grafana" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (Grafana will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.small).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Grafana

You can set up the Grafana application through the "DashboardUrl" or "DashboardUrlIp" provided in the "Outputs" tab. This will allow you to create an Admin account, and all future accounts will be created through the Admin panel.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

On your first login, Grafana will automatically prompt you to set a new, strong Administrator password. This is a mandatory step to secure your deployment.

The Administrator Account you create will have full access to manage the entire workspace—this includes inviting team members, configuring system settings, and maintaining access control.

Be sure to choose a strong password and store your credentials securely, as they are essential for future access and team management.

Generate SSL Manually

Grafana will automatically try to setup SSL based on provided domain name, if that domain is hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter, and follow the instructions

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo tail -f /var/log/grafana/grafana.log

Shutting Down Grafana

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the Grafana instance in EC2.

2. Select the grafana instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove Grafana

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.
Then reboot the instance and restart the Grafana service.

Conclusion

The Meetrix Grafana Deployment Guide is your go-to resource for seamlessly integrating Grafana into your AWS environment. Whether you're a DevOps engineer, system administrator, or IT leader, our guide provides clear, step-by-step instructions to ensure a secure, scalable, and production-ready setup.

Grafana is a powerful open-source observability platform built for high-trust environments, empowering teams with real-time monitoring, alerting, automation, and flexible data source integrations.

With the Meetrix Grafana Deployment Guide, you'll unlock the full potential of Grafana, enabling your organization to build efficient, secure, and self-hosted dashboards and monitoring systems that scale with your infrastructure.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with Grafana issues.

Deploy Moodle on AWS with Meetrix - The Leading Open-Source LMS, Pre-Configured for Instant Use

Shalomi Umeshika — Mon, 28 Jul 2025 06:55:59 GMT

Launch a secure, scalable Moodle environment in minutes, optimized for education, training, and 24/7 uptime

As online education and remote training continue to grow across industries, organizations need reliable learning platforms that are customizable, cost-effective, and secure. Moodle, the world’s most popular open-source learning management system (LMS) is the platform of choice for universities, schools, government institutions, and training providers worldwide.

But deploying Moodle at scale isn’t always simple. Managing PHP versions, configuring databases, enabling SSL, and optimizing performance can delay your project and introduce security risks.

That’s why Meetrix offers a fully configured Moodle deployment on AWS, purpose-built for fast launch, secure operation, and supported by a 24/7 expert team.

Resources to Get Started
YouTube Video Walkthrough
Moodle Developer Guide

What Is Moodle?

Moodle is a powerful, open-source learning platform that enables educators to build custom digital classrooms. It supports:

Course creation and management
Role-based user access (students, teachers, admins)
Multimedia lesson delivery
Quizzes, forums, and collaborative tools
Integration with SCORM, LTI, H5P, and external tools
Learning analytics and reporting

Moodle is used by over 300 million users in 240+ countries, making it one of the most trusted LMS platforms in the world.

How the Deployment Works

For teams who want to understand the setup, Meetrix provides a step-by-step Developer Guide. Here’s a quick summary of what’s included:

Launch the AMI
Deploy Moodle instantly from the AWS Marketplace using our pre-configured AMI.

Secure Setup
HTTPS/SSL enabled by default (Let’s Encrypt support)
IAM-based access controls integrated with AWS best practices

Database & Storage
Uses MariaDB/PostgreSQL backend with tuned configurations for performance
Scalable storage setup on Amazon EBS, with support for external databases if needed

Customization
Full root/admin access for installing plugins, themes, and custom modules
Easy DNS mapping through Route 53

Scaling & Performance
Built-in caching for high concurrency
Load-balancer and autoscaling ready (can expand for thousands of concurrent users)

This setup ensures your Moodle environment is production-ready out of the box, with flexibility to scale and extend as your user base grows.

Why Choose Meetrix for Moodle Deployment?

While Moodle is freely available, deploying and managing it properly in a cloud production environment takes time, expertise, and monitoring. Meetrix simplifies this process by delivering a ready-to-use Moodle instance, optimized for performance, scalability, and security within your own AWS account.

Included in Meetrix’s Moodle Deployment:

Latest Moodle LTS version, fully installed and configured
Web server stack (NGINX/Apache, PHP, MariaDB/PostgreSQL)
SSL/HTTPS setup with domain support
Hardened security settings and IAM best practices
Optimized caching and session management
24/7 expert technical support for your team

Who Uses Moodle?

Meetrix's solution is ideal for:

Universities and colleges deploying campus-wide e-learning
K-12 schools needing remote or blended learning solutions
Corporate L&D teams running internal training and certifications
Government and NGOs training employees or public learners
Professional educators and tutors looking for full control over their LMS
Training providers delivering SCORM-compliant online courses

Key Industry Use Cases

Segment	Use Case Examples
Higher Education	Host thousands of courses, assignments, and exams for students
K-12 Schools	Deliver remote or hybrid instruction with parent access
Corporate Training	Onboard staff provide role-based certification and tracking
Nonprofit Training	Create multilingual e-learning for global outreach
Government	Deploy secure internal training systems behind a firewall
EdTech Startups	Build LMS-based products or services for clients

Benefits of Using Meetrix for Moodle Hosting

Feature	Meetrix Moodle Deployment	DIY Setup
Setup Time	Under 10 minutes	Several hours or days
SSL/HTTPS	Pre-configured with certificates	Manual setup required
Database + PHP Optimization	Tuned for high performance	Default settings
Security & Access Control	IAM & firewall best practices	Must configure from scratch
Support	24/7 expert human support	Community forums only

Frequently Asked Questions

Can I customize the Moodle theme and plugins?
Yes. Meetrix supports full admin access, allowing you to upload and configure themes, modules, and integrations.

Is Moodle mobile-friendly?
Absolutely. Moodle includes responsive design and a dedicated mobile app for learners and instructors.

Can this deployment support large numbers of users?
Yes. We help clients scale from a few hundred to tens of thousands of concurrent learners using Moodle’s built-in scalability features.

Is the solution compliant with education data standards (FERPA, GDPR, etc.)?
Yes. Because you own the AWS environment, we can help you configure access, logging, and encryption to meet strict compliance requirements.

Power Your Learning with Moodle, Hosted and Supported by Experts

Moodle offers everything you need to create engaging, flexible, and powerful learning experiences without vendor lock-in or costly licenses. And with Meetrix handling the infrastructure, security, and setup, you get the fastest path to launching a production-ready Moodle environment.

Whether you're an academic institution scaling up remote learning or an enterprise standardizing corporate training, Meetrix helps you deploy Moodle confidently, with performance, security, and 24/7 support built in.

Launch your Moodle instance with Meetrix. Empower learning without limits.
Get Started with Moodle Deployment by Meetrix on AWS

Open WebUI- Developer Guide

Maneesha Shehara — Mon, 28 Jul 2025 03:55:59 GMT

Open WebUI brings real-time collaboration, LLM integration, and workflow automation to your AWS environment. Designed for high-trust enterprise use cases, it enables secure, scalable deployments with minimal setup. Empower your teams with an intuitive interface for managing AI workloads and enhancing productivity.

Prerequisites

Before you get started with the Open WebUI AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''Open WebUI'' AMI

Log in to your AWS Management Console.
Navigate to the 'Open WebUI' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy Open WebUI" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (Open WebUI will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.medium).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Open WebUI

You can set up the Open Web UI application through the "DashboardUrl" or "DashboardUrlIp" provided in the "Outputs" tab. This will allow you to create an Admin account, and all future accounts will be created through the Admin panel.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Enter all the required details and click on the “Create Account” button.

Important: You are now creating the Admin Account for your Open WebUI deployment. The email address and password you provide here will be used to manage your entire workspace including inviting team members, configuring system settings, and maintaining overall access.

Make sure to choose a strong password and store your credentials securely, as they are critical for future access and team management.

Generate SSL Manually

Open WebUI will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter, and follow the instructions

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo docker ps

Select the correct container and check logs

sudo docker logs d1
sudo docker logs 43

Shutting Down Open WebUI

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the Open Web UI instance in EC2.

2. Select the Open Web UI instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove Open Web UI

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.
Then reboot the instance and restart the Open Web UI service.

Conclusion

The Meetrix Open WebUI AMI empowers teams to quickly deploy a secure, scalable, and fully self-hosted collaboration platform on AWS. Whether you're a DevOps engineer, IT admin, or enterprise architect, our solution enables real-time communication, automation, and seamless LLM integration all within your own cloud environment. Unlock the full potential of Open WebUI with our step-by-step deployment guide and build a platform that grows with your organization.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with Open Web UI issues.

Directus - Developer Guide

Maneesha Shehara — Wed, 23 Jul 2025 09:53:37 GMT

Welcome to the Directus AWS Deployment Guide. Seamlessly integrate Directus with AWS for scalable, secure, and automated operations. Enhance team productivity with real-time collaboration and workflow orchestration in high-trust, enterprise environments. Let's get started.

Prerequisites

Before you get started with the Directus AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select ''Directus'' AMI

Log in to your AWS Management Console.
Navigate to the 'Directus' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy Directus" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (Directus will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.small).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Directus

You can set up the Directus application through the "DashboardUrl" or "DashboardUrlIp" provided in the "Outputs" tab. This will allow you to create an Admin account, and all future accounts will be created through the Admin panel.

(If you encounter a "502 Bad Gateway error", please wait for about 5 minutes before refreshing the page)

Enter all the required details and click on the “Create Account” button.

Important: You are now creating the Administrator Account for your Directus deployment. The email address and password you provide here will be used to manage your entire workspace, including inviting team members, configuring system settings, and maintaining overall access.

Make sure to choose a strong password and store your credentials securely, as they are critical for future access and team management.

Generate SSL Manually

Directus will automatically try to setup SSL based on provided domain name, if that domain is hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter, and follow the instructions

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo docker ps

Select the correct container and check logs

sudo docker logs d1
sudo docker logs 43

Shutting Down Directus

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the Directus instance in EC2.

2. Select the Directus instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove Directus

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.
Then reboot the instance and restart the Directus service.

Conclusion

The Meetrix Directus Deployment Guide is your go-to resource for seamlessly integrating Directus into your AWS environment. Whether you're a DevOps engineer, system administrator, or IT leader, our guide provides clear, step-by-step instructions to ensure a secure and scalable setup. Directus is a powerful open-source collaboration platform built for high-trust environments, empowering teams with real-time communication, automation, and integration flexibility. With the Meetrix Directus Deployment Guide, you'll unlock the full potential of Directus, enabling your organization to build efficient, secure, and self-hosted communication systems that scale with your needs.

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with Directus issues.

Apache-NiFi - Developer Guide

Maneesha Shehara — Wed, 23 Jul 2025 09:53:10 GMT

Welcome to the Apache NiFi Deployment Guide for AWS Integration! Unlock the full power of Apache NiFi, the open-source data orchestration platform designed for robust data flows. Seamlessly integrate with your AWS infrastructure to achieve enterprise-grade scalability, secure data processing, and DevOps-friendly automation. Empower your teams with real-time data ingestion, workflow orchestration, and extensibility for mission-critical operations. Let's get started and elevate your data management with NiFi on AWS.

Prerequisites

Before you get started with the Apache-NiFi AMI, ensure you have the following prerequisites:

Basic knowledge of AWS services, including EC2 instances and CloudFormation.
An active AWS account with appropriate permissions.
Enough vCPU limit to create instance
(Follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to ensure this)

Launching the AMI

Step 1: Find and Select Apache-NiFi AMI

Log in to your AWS Management Console.
Navigate to the 'Apache-NiFi' in AWS Marketplace.

Step 2: Initial Setup & Configuration

Click the "Continue to Subscribe" button.
After subscribing, you will need to accept the terms and conditions. Click on "Accept Terms" to proceed.
Please wait for a few minutes while the processing takes place. Once it's completed, click on "Continue to Configuration".
Select the "CloudFormation script to deploy Apache-NiFi" as the fulfilment option and choose your preferred region on the "Configure this software" page. Afterward, click the "Continue to Launch" button.
From the "Choose Action" dropdown menu in "Launch this software" page, select "Launch CloudFormation" and click "Launch" button.

Create CloudFormation Stack

Step1: Create stack

Ensure the "Template is ready" radio button is selected under "Prepare template".

2. Click "Next".

Step2: Specify stack options

Provide a unique "Stack name".
Provide the "Admin Email" for SSL generation.
For "DeploymentName", enter a name of your choice.
Provide a public domain name for "DomainName" (Apache-NiFi will automatically try to set up SSL based on provided domain name, if that domain hosted on Route53. Please make sure your domain name hosted on route53. If its unsuccessful then you have to setup SSL manually)
Choose an instance type, "InstanceType" (Recommended: t3.medium).
Select your preferred "keyName".
Set "SSHLocation" as "0.0.0.0/0".
Keep "SubnetCidrBlock" as "10.0.0.0/24".
Keep "VpcCidrBlock" as "10.0.0.0/16".
Click "Next".

Step3: Configure stack options

Choose "Roll back all stack resources" and "Delete all newly created resources" under the "Stack failure options" section.
Click "Next".

Step4: Review

Review and verify the details you've entered.

2. Tick the box that says, "I acknowledge that AWS CloudFormation might create IAM resources with custom names".

3. Click "Submit".

Afterward, you'll be directed to the CloudFormation stacks page.

Please wait for 5-10 minutes until the stack has been successfully created.

Update DNS

Step1: Copy IP Address

Copy the public IP labeled "PublicIp" in the "Outputs" tab.

Step2: Update DNS

Go to AWS Route 53 and navigate to "Hosted Zones".
From there, click on Create record.

3. Add the record name and then paste the copied "PublicIp" into the "value" textbox.

4. Click "Save".

Access Apache-NiFi

Once the stack has been successfully created, you must configure SSL before attempting to access the Apache NiFi application. Without SSL, the application will not be accessible.

You can access the Apache NiFi interface exclusively through the "DashboardUrl" provided in the "Outputs" section of your CloudFormation stack. Direct access via the public IP address is not supported.

Upon first login, you will be prompted to create an Admin account. All subsequent user accounts must be created through the Admin panel.

Note: If you receive a “502 Bad Gateway” error, please wait approximately 5 minutes and refresh the page. The application may still be initializing.

Please enter the Username and Password that you have provided. Ensure both are stored securely for future reference.

Generate SSL Manually

Apache-NiFi will automatically try to setup SSL based on provided domain name, if that domain hosted on Route53. If its unsuccessful then you have to setup SSL manually.

Step1: Copy IP Address

Proceed with the instructions outlined in the above "Update DNS" section, if you have not already done so.
Copy the Public IP address indicated as "PublicIp" in the "Outputs" tab.

Step2: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@.

3. Type "yes" and press Enter. This will log you into the server.

Step3: Generate SSL

Paste the following command into your terminal and press Enter, and follow the instructions

sudo /root/certificate_generate_standalone.sh

Admin Email is acquiring for generate SSL certificates.

Check Server Logs

Step1: Log in to the server

Open the terminal and go to the directory where your private key is located.
Paste the following command into your terminal and press Enter:

ssh -i  ubuntu@

3. Type "yes" and press Enter. This will log you into the server.

Step2: Check the logs

sudo docker ps

Select the correct container and check logs

sudo docker logs 0e

Shutting Down Apache-NiFi

Click the link labeled "Instance" in the "Resources" tab to access the EC2 instance, you will be directed to the Apache-NiFi instance instance in EC2.

2. Select the Apache-NiFi instance instance by marking the checkbox and click "Stop instance" from the "Instance state" dropdown. You can restart the instance at your convenience by selecting "Start instance".

Remove Apache-NiFi

Delete the stack that has been created in the AWS Management Console under 'CloudFormation Stacks' by clicking the 'Delete' button.

Upgrades

Troubleshoot

If you face the following error, please follow https://meetrix.io/articles/how-to-increase-aws-quota/ blog to increase vCPU quota.

2. If you face the following error (do not have sufficient capacity...) while creating the stack, try changing the region or try creating the stack at a later time.

3. If you face the below error, when you try to access the API dashboard, please wait 5-10 minutes and then try.

4. Check whether the instance storage is full.

Log into the server and run the below command

df -h

root volume

If the root volume is between 90-100%, it is better to resize EBS volume. Please follow AWS documentation to increase the EBS volume.
Then reboot the instance and restart the Apache-NiFi instance service.

Conclusion

The Meetrix Apache NiFi Deployment Guide is your go-to resource for seamlessly integrating NiFi into your AWS environment. Whether you're a DevOps engineer, data architect, or IT leader, our guide provides clear, step-by-step instructions to ensure a secure and scalable setup. Apache NiFi is a powerful open-source data orchestration platform built for high-trust environments, empowering teams with real-time data ingestion, automation, and integration flexibility. With the Meetrix Apache NiFi Deployment Guide, you'll unlock the full potential of NiFi, enabling your organization to build efficient, secure, and self-hosted data pipelines that scale with your needs

Technical Support

Reach out to Meetrix Support (aws@meetrix.io) for assistance with Apache-NiFi instance issues.

LLaMA 4 Scout by Meetrix on AWS Marketplace: Your Gateway to Multimodal AI

Shalomi Umeshika — Tue, 22 Jul 2025 11:00:00 GMT

Meta’s most advanced open-source vision-language model, ready to deploy with Meetrix

As AI evolves from single-modal chatbots to multimodal agents that can see and read, the demand for scalable, open-source solutions is growing rapidly. LLaMA 4 Scout, developed by Meta, represents a leap forward in large language models, natively multimodal, highly efficient, and trained on massive web-scale datasets.

With Meetrix’s pre-configured AMI, you can now deploy LLaMA 4 Scout directly from AWS Marketplace, without wrestling with dependencies, GPU drivers, or infrastructure. Just launch, run, and build.

What Is LLaMA 4 Scout?

LLaMA 4 Scout is part of Meta’s latest generation of open-source models, a natively multimodal model designed to seamlessly handle both text and image inputs in a single pipeline. This eliminates the need for multiple encoders or custom fusion layers.

Key Features:

Mixture-of-Experts (MoE) design with 16 experts, 2 active per token
17 billion active parameters for efficient, high-quality inference
Released openly under a permissive license

Why Choose Meetrix?

Deploying LLaMA 4 Scout manually can take hours or even days. With Meetrix, you're ready in minutes, with enterprise-grade infrastructure and human support.

What’s included in our AWS AMI:

Pre-installed libraries and dependencies (PyTorch, Transformers, CUDA, etc.)
GPU-accelerated environment ready for AWS g4 instances
Hardened configuration with SSH, firewall, and IAM best practices
REST-ready model serving options
24/7 technical support and optional consulting services

Use Cases

Use Case	Industry Examples	What LLaMA 4 Scout Can Do
Multimodal Customer Support	E-commerce, SaaS, Fintech	Agents that understand screenshots, bills, or photo uploads
Compliance & Audit Automation	Healthcare, Pharma, HR	Review and summarize images/documents for policy violations or approval
Educational Tutoring Agents	EdTech, Nonprofits	AI tutors that explain graphs, diagrams, or annotated content
Accessibility Support Tools	Media, Design, Web Agencies	Generate alt-text, captions, and content summaries for visual media
Multimodal Coding Copilot	DevOps, Software Agencies	Explain architecture diagrams, UI mockups, or screenshots of code errors
Geospatial or Map QA	Defense, Logistics, Infrastructure	Ask questions about satellite images, maps, floor plans
Visual Sentiment & Moderation	Social Media, Gaming, Publishing	Detect content themes, risk flags, and bias from images + captions

Who Should Use LLaMA 4 Scout?

AI/ML Developers needing local or private inference
Startups looking to prototype multimodal products without vendor lock-in
Research labs and universities experimenting with vision-language alignment
Enterprises integrating intelligent document and visual analysis into workflows
Government and defence organisations deploying AI in secure VPC environments

Market Segments We Serve

SaaS & GenAI Startups
Fintech & InsurTech
Healthcare & Life Sciences
E-commerce & Digital Retail
Education & Academic Research
Public Sector & Defence

Technical Highlights

Architecture: Mixture-of-Experts (MoE)
Active Parameters: 17B
Modalities: Text
Environment: Ubuntu 22.04 with PyTorch, HuggingFace, CUDA
Compatible Instance: g4dn.metal

Competitive Advantage

Feature	Meetrix AMI	DIY Deployment
Setup Time	< 10 minutes	Hours or days
GPU Support	Pre-installed & tested	Manual CUDA/drivers required
Security	AWS-hardened with firewall & VPC	Manual setup needed
Updates	Maintained with model compatibility	Must be managed manually
Support	24/7 human support	None or community only
Optional Consulting	Yes	No

FAQs

Does it support REST or API integration?
Yes. You can expose Flask/FastAPI endpoints or connect it to LangChain and similar orchestration tools.

Can I run it without a GPU?
Technically, yes, but performance will be very limited. We strongly recommend GPU instances for production inference.

Is it production-ready?
Absolutely. The AMI is configured for secure, scalable deployments in your own AWS VPC.

Build the Future of AI with Confidence

The next generation of AI applications won’t just read or respond, they’ll see, understand, and interact in ways that mirror human intelligence. With LLaMA 4 Scout, Meta has delivered one of the most powerful open-source multimodal models to date, combining language fluency with visual reasoning in a single, efficient architecture.

But power alone isn’t enough; you need speed, simplicity, and support to turn potential into production.

That’s exactly what Meetrix’s LLaMA 4 Scout AMI on AWS Marketplace delivers.

Whether you’re a startup prototyping a multimodal chatbot, an enterprise integrating AI into your workflow, or a research lab pushing the boundaries of visual understanding, Meetrix gives you the tools to move faster and smarter.

Skip the complex installs. Avoid cloud lock-in. Deploy in minutes. Innovate without limits.

Start building with LLaMA 4 Scout today. The infrastructure is ready. Are you?

Launch LLaMA 4 Scout by Meetrix on AWS Marketplace

Self-Host Supabase with Meetrix on AWS - The Open-Source Firebase Alternative, Ready in Minutes

Shalomi Umeshika — Mon, 21 Jul 2025 10:24:10 GMT

Launch your own Supabase backend in minutes with a fully managed deployment and 24/7 expert support

In today’s competitive software landscape, application teams need to move fast, without compromising on security, scalability, or data control. That’s why many developers are turning to Supabase, a full-featured, open-source backend-as-a-service (BaaS) platform that provides everything from database and authentication to storage and real-time functionality.

But setting up Supabase in your own cloud environment requires significant effort: managing Docker containers, configuring TLS certificates, enabling PostgreSQL backups, and optimizing performance for production traffic.

That’s where Meetrix comes in.

We offer a ready-to-deploy Supabase stack for AWS that gives you all the benefits of Supabase Cloud, but hosted in your account, fully secured, and supported 24/7 by experts.

What Is Supabase?

Supabase is an open-source backend platform that replicates Firebase’s core features, but with the transparency and flexibility of a self-hosted model built on PostgreSQL.

Supabase provides:

A relational PostgreSQL database with REST and GraphQL API
Authentication with email/password, social logins, and OAuth
Real-time subscriptions using PostgreSQL replication
Secure object storage with role-based access
Serverless functions for custom backend logic
Admin dashboard (Studio) for managing your project

With Supabase, you get modern backend capabilities without black-box restrictions or lock-in.

Why Self-Host Instead of Using Supabase Cloud?

Supabase Cloud is great for early-stage prototyping, but many teams choose self-hosting for:

Regulatory compliance (GDPR, HIPAA, SOC2)
Full data control and infrastructure visibility
VPC networking, IAM integration, and custom monitoring
Predictable infrastructure costs with no user-based pricing
Extending, modifying, or integrating with existing systems

Meetrix’s self-hosted deployment gives you all this, without the complexity.

What Does Meetrix Provide?

We deliver a turnkey Supabase deployment that installs all essential components and configures your environment for production-readiness.

Included:

Supabase services: PostgreSQL, Auth, Storage, Realtime, Edge Functions, Studio
Secure HTTPS access with NGINX reverse proxy
IAM-ready infrastructure and firewall best practices
PostgreSQL optimization for performance and backups
Optional logging, monitoring, and autoscaling
24/7 expert support and optional consulting

Start Quickly With Our Developer Guide

To help developers accelerate their adoption, we've published a step-by-step Supabase Developer Guide that covers:

Initial configuration
Accessing the dashboard
Customizing authentication
Managing storage buckets
Connecting to APIs securely

Read the guide here:
https://meetrix.io/articles/supabase-developer-guide/

Video Walkthrough on YouTube:
Watch the YouTube video guide

You can also deploy your Supabase backend directly using our AWS deployment offering:
Launch Supabase by Meetrix on AWS Marketplace

Who Should Use This?

Our pre-configured Supabase deployments are designed for:

Developers and SaaS startups launching production-ready apps
Enterprises with sensitive data and strict security requirements
DevOps and infrastructure teams looking to standardize backend delivery
Agencies deploying multiple custom app environments
Educational, healthcare, and government orgs requiring control and compliance

Industry Use Cases

Industry	Example Applications
SaaS	Multi-tenant platforms, secure APIs, user onboarding flows
Fintech	KYC systems, encrypted data storage, secure identity management
Healthcare	HIPAA-friendly portals, form processing, consent tracking
Education	Student dashboards, learning content platforms, secure logins
E-commerce	Product catalogs, user reviews, order tracking systems
Public Sector	Internal tools with strict data control and authentication

Key Benefits

Feature	Meetrix Supabase Deployment	Manual Setup
Setup Time	Under 10 minutes	Hours to days
SSL + Reverse Proxy	Pre-configured	Requires NGINX setup
Infrastructure Security	Hardened and IAM-ready	Needs manual tuning
PostgreSQL Optimization	Tuned for production	Default configs
Support	24/7 expert support	Community forums only
Optional Consulting	Available	Not included

Frequently Asked Questions

Is this the same as Supabase Cloud?
No. This is a self-hosted deployment of the open-source Supabase stack, hosted in your own AWS account.

Is Supabase Studio included?
Yes. You’ll get full access to the browser-based Supabase admin interface over HTTPS.

Can I scale this setup?
Yes. The infrastructure is designed to support vertical and horizontal scaling. We can assist with load balancing, backups, and multi-region setups.

Can I migrate from Supabase Cloud?
Yes. We can help you move your database, storage, and auth settings from Supabase Cloud to your self-hosted environment.

Take Full Ownership of Your App Backend

Supabase brings the speed and simplicity of Firebase, with the openness and extensibility of PostgreSQL. With Meetrix’s support, you can self-host Supabase confidently in your AWS environment, fully secured, performance-optimized, and production-ready.

Whether you're launching a SaaS product, migrating from Firebase, or building secure internal tools, Meetrix helps you move faster and stay in control.

Own your backend. Launch in minutes. Build with confidence.
Start Your Supabase Deployment with Meetrix on AWS
